Proton Optical Pod (PVS)
Proton Optical Pod (PVS) – Image 2

Proton Optical Pod (PVS)

519,00 € Excl. Tax

The Proton Optical Pod is the core optical module of the Proton platform. Built from aerospace-grade aluminum and designed to be individually sealed and purged, each pod delivers reliable, high-performance night vision while staying easy to service, upgrade, and reconfigure from mono to bino.

DISCLAIMER: This product only includes the pod without optics or tubes

Proton Optical Pod

The Proton Optical Pod is the heart of the Proton night-vision platform. Each pod is a fully independent optical module, designed to host a small-format ANVIS / MX10160 image intensifier. Built from aerospace-grade aluminum and sealed to withstand harsh environments, it provides a rugged, modular foundation for both monocular and binocular configurations.

Modular by Design

  • Use a single pod as a compact monocular, or combine two pods on a Proton Lite bridge to build a full binocular system.
  • Each pod is mechanically independent, making upgrades, replacements, and configuration changes simple and fast.
  • Designed for users who want a long-term platform they can adapt to their needs over time.

Individually Sealed & Purged

  • Each optical pod can be individually sealed and nitrogen-purged.
  • The atmosphere inside the pod remains isolated from the rest of the system.
  • Any disassembly on the bridge or accessories does not compromise the integrity of the optical module.

Rugged Construction

  • Aerospace-grade 7075-T6 aluminum housing.
  • Type III hard anodized finish for maximum wear and corrosion resistance.
  • Submersible construction designed for demanding field conditions.

Optical Performance

  • Compatible with small-format ANVIS / MX10160 image intensifier tubes.
  • Optimised for a 40° ± 2° field of view with standard mil-spec optics.
  • Diopter adjustment range (with standard eyepiece optics): approx. +2 to −6.

Serviceable, Long-Lived Platform

  • Low-tech, feature-rich design focused on reliability rather than gimmicks.
  • Field maintenance and part replacement are straightforward and do not require specialist equipment.
  • Ideal for users who want to keep their system operational for the long term, with minimal downtime.

Compatibility

  • Compatible with Proton Lite binocular chassis / bridge.
  • Works with the Proton Lite-O monocular adapter to build a single-eye configuration.
  • Accepts standard small ANVIS / MX10160 image intensifier format.

Key Features

  • Independent, fully sealed optical pod.
  • Aerospace-grade 7075-T6 aluminum body.
  • Type III hard anodized finish.
  • Optimised for 40° ± 2° FOV (with standard optics).
  • Designed for small ANVIS / MX10160 tubes.
  • Modular: mono or bino depending on configuration.

Included

  • 1 × Proton Optical Pod (housing only, without image intensifier).
  • 1 × Tube locking ring,
  • 1 × Eyepiece Locking Ring
  • 1 × Objective Infinity Locking Ring
  • 1 × Objective Close Focus Stop Ring
  • 4 × Extra screws
